Best Choice in Li-Ion technology for the ongoing evolution.

About us

The TerraE is a high quality cylindrical battery cells provider, owned by Sven Bauer, CO & Founder of BMZ Group, global leading solution provider for batteries and chargers, headquartered in Germany.


For the BMZ GroupTerraE initiative is the next big milestone in building a sustainable and complete supply chain providing best in class Li-Ion technology.



TerraE’s executive managers, engineers and technicians define specifications for battery cells, which are manufactured accordingly on existing lines by tier-one suppliers in Asia under the brand TerraE.

Many of BMZ international well known customers are already successfully using the TerraE battery cells for a wide range of applications: energy storage systems (ESS), electric vehicles, e-bikes, power and garden tools, medical equipment, home and industrial appliance.
Technology
TerraE cells are cylindrical type, available in 4 sizes known and widely used in the industry: 14500 / 18650/ 21700 / 26650.

Almost in every size two main chemistries can be found: NMC/NCA and LFP.
The NMC/NCA chemistry TerraE cells are also available from both main types:
high energy (showing high energy density and long cycle life, used in LEV, EV and other) and high power (capable for high charge and discharge rates, used in power tools and other).
Cells are produced by leading battery cell manufacturers.

High advanced materials + produced on state-of-the-art production lines + best in class production process control = TOP QUALITY TERRAE CELLS
Applications
E-Mobility
Drive Systems
Energy Storage
Garden Tools
Power Tools
Home Appliance
Industrial
Medical
We provide comprehensive cylindrical lithium-ion battery cells and customizable solutions for the world.
LITHIUM ION CELLS

Best Choice in Li-Ion technology for the ongoing evolution.


+HighHigherHighestPower

+HighHigherHighestCapacity

+LongLongerLongestLifetime

+Stop-One-Stop-Shop

+ Supply ensured withtermlong-termpartner

+ Cell availability inlargesmalllarge and smallquantities

BATEMO CELL EXPLORER

Use the free Batemo Cell Explorer below to find and compare battery cells.

Our privacy policy applies. The Cell Explorer will eventually load Google Fonts

KEY FACTS

INR 18650 32P

Model
INR_18650_32P
Capacity
3000 mAh
Max. Discharge Current
10C
Nominal Voltage
3.6 V
Weight of Bare Cell
47 g
Internal Impedance
≤25 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

IFR 18650 11P

Model
IFR_18650_11P
Nominal Capacity
1100 mAh
Min. Capacity
1100 mAh
Max. Discharge Current
30C
Nominal Voltage
3.2 V
Weight of Bare Cell
39,5 g
Internal Impedance
≤18 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +55°C
Download

INR 18650 22E

Model
INR_18650_22E
Nominal Capacity
2200 mAh
Min. Capacity
2100 mAh
Max. Discharge Current
15A
Nominal Voltage
3.6 V
Weight of Bare Cell
45 g
Internal Impedance
≤20 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

INR 18650 25P

Model
INR_18650_25P
Nominal Capacity
2500 mAh
Min. Capacity
2450 mAh
Max. Discharge Current
30A
Nominal Voltage
3.6 V
Weight of Bare Cell
48 g
Internal Impedance
≤20 mΩ
Operating Environmental Temperature Discharge
-Up to +80°C
Operating Environmental Temperature Charge
Up to +55°C
Download

INR 18650 20P

Model
INR_18650_20P
Nominal Capacity
2000 mAh
Min. Capacity
1950 mAh
Max. Discharge Current
30A
Nominal Voltage
3.6 V
Weight of Bare Cell
45 g
Internal Impedance
≤20 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

INR 21700 40P

Model
INR_21700_40P
Nominal Capacity
4000 mAh
Min. Capacity
3900 mAh
Max. Discharge Current
45A
Nominal Voltage
3.6 V
Weight of Bare Cell
65±2g
Internal Impedance
≤12 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

INR 18650 30E

Model
INR_18650_30E
Nominal Capacity
3000 mAh
Min. Capacity
2900 mAh
Max. Discharge Current
6A
Nominal Voltage
3.65 V
Weight of Bare Cell
48 g
Internal Impedance
≤35 mΩ
Operating Environmental Temperature Discharge
-20°C up to +55°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

INR 21700 50E

Model
INR_21700_50E
Nominal Capacity
5000 mAh
Min. Capacity
4900 mAh
Max. Discharge Current
15A
Nominal Voltage
3.6 V
Weight of Bare Cell
70 g
Internal Impedance
≤30 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

INR 18650 35E

Model
INR_18650_35E
Nominal Capacity
3350 mAh
Min. Capacity
3250 mAh
Max. Discharge Current
10A
Nominal Voltage
3.6 V
Weight of Bare Cell
≤50 g
Internal Impedance
≤35 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +45°C
Download

INR 21700 58E

Model
INR_21700_50E
Nominal Capacity
5700 mAh
Min. Capacity
5650 mAh
Max. Discharge Current
15A
Nominal Voltage
3.6 V
Weight of Bare Cell
75 g
Internal Impedance
≤30 mΩ
Operating Environmental Temperature Discharge
-20°C up to +60°C
Operating Environmental Temperature Charge
0°C up to +50°C
Download
